| CQD-A STAND-ON ELECTRIC REACH FORKLIFT TECHNICAL PARAMETERS | ||||||
| Feature | 1 | Model | CQD | |||
| 2 | Configuration No. | 1530-A | 2030-A | |||
| 3 | Drive | electric | ||||
| 4 | Steering mode | electronic steering | ||||
| 5 | Type of operation | stand on | ||||
| 6 | Load capacity | Q | kg | 1500 | 2000 | |
| 7 | Load center | C | mm | 500 | ||
| 8 | Load distance | X | mm | 130 | ||
| 9 | Wheel base | Y | mm | 1370 | ||
| Weight | 1 | Service weight with battery | kg | 1925 | 2100 | |
| Wheels | 1 | Wheels type | PU | |||
| 2 | Driving wheel size | mm | Ф230×75 | |||
| 3 | Balance wheel size | mm | Ф125×60 | |||
| 4 | Bearing wheel size | mm | Ф210×85 | |||
| 5 | Wheel quantity(front /rear)(x=Driving wheel) | 1x-2/2 | ||||
| 6 | Track width,front | mm | 985 | |||
| 7 | Track width,rear | mm | 700 | |||
| Dimension | 1 | Overall length(mast closed/extended) | L1 | mm | 2325/2830 | 2525/3030 |
| 2 | Overall width | b1 | mm | 1090 | ||
| 3 | Mast lowered height | h1 | mm | 2030 | ||
| 4 | Free lift | h2 | mm | 90 | ||
| 5 | Lift height | h3 | mm | 3000 | ||
| 6 | Extended mast height | h4 | mm | 3940 | ||
| 7 | Lowered fork height | S | mm | 40 | ||
| 8 | Handle ground clearance(Max/Min) | h6 | mm | 1487/1070 | ||
| 9 | Fork size | s/e/l | mm | 40/100/1070 | ||
| 10 | Overall fork width | b3 | mm | 220-610 | ||
| 11 | Reach distance | 500 | ||||
| 12 | Min.ground clearance | m2 | mm | 55 | ||
| 13 | Min.Aisle width for pallets 1000×1200 | Ast | mm | 2650 | 2850 | |
| 14 | Turning radius | Wa | mm | 1670 | ||
| 15 | Inner width between tracks | b4 | mm | 770 | ||
| Performance | 1 | Travel speed(laden/unladen) | km/h | 6/6.2 | ||
| 2 | Lift speed(laden/unladen) | mm/s | 105/150 | |||
| 3 | Lowering speed(laden/unladen) | mm/s | 220/105 | |||
| 4 | Gradeability(laden/unladen) | % | 5/8 | |||
| 5 | Brake | electromagnetic | ||||
| Electrical configuration | 1 | Drive motor | kw | AC 1.5 | ||
| 2 | Lift motor | kw | 3 | |||
| 3 | Battery voltage/capacity | V/Ah | 24/240 | |||
| 4 | Battery weight | kg | 200 | |||
| Other Details | 1 | Type of drive control | AC | |||
| 2 | Sound leave at driver's ear to EN 12053 | dB(A) | <70 | |||
| Height Parameters | |||
| Mast lowered height | Free lift | Lift height | Extended mast height |
| h1(mm) | h2(mm) | h3(mm) | h4(mm) |
| 2130 | 1600 | 1600 | 2540 |
| 1780 | 90 | 2500 | 3440 |
| 2030 | 90 | 3000 | 3940 |
| 2310 | 90 | 3500 | 4440 |
| 2590 | 90 | 4000 | 4940 |
| 2060 | 1500 | 4500 | 5340 |
