ONEN Stand-on Electric Counterbalance Forklift is suitable for handling and stacking of a variety of pallets. The stand-on design reduces labor intensity, compact body with ultra-small turning radius is widely used in warehouses, supermarkets, workshops, and homes for loading and unloading and moving goods.
| CPDD-A Stand-On Electric Counterbalance Forklift | |||||||||
| Features | Product model | CPDD-A1530 | |||||||
| Power type | Electric | ||||||||
| Driving way | Stand on | ||||||||
| Rated load | Q kg | 1500 | |||||||
| Load center | C mm | 500 | |||||||
| Front overhang | X mm | 126 | |||||||
| Wheel base | Y mm | 1370 | |||||||
| Weight | self-weight(include battery) | kg | 2030 | ||||||
| Wheel | Tire | Polyurethane wheels | |||||||
| Driving wheel | mm | Φ230×75 | |||||||
| Bearing wheel | mm | Φ210x85 | |||||||
| Balance wheel | mm | Φ125×60 | |||||||
| Wheel number(Front/rear)(x=driven wheel) | 1x-2 | ||||||||
| Front wheel span | mm | 883 | |||||||
| Real wheel span | mm | 700 | |||||||
| Size | Overall height(Closed) | h1 mm | See below schedule for details. | ||||||
| Free lifting height | h2 mm | ||||||||
| Max. lifting height | h3 mm | ||||||||
| Overall height(Extended) | h4 mm | ||||||||
| Fork clearance from the ground | h5 mm | 40 | |||||||
| Overall length | L1 mm | 2830 | |||||||
| Overall width | b1 mm | 996 | |||||||
| Fork size | s/e/l mm | 40/100/1070 | |||||||
| Fork outer width | b3 mm | 220-650 | |||||||
| Min. ground clearance | m mm | 55 | |||||||
| Aisle width for pallet 800*1200 | Ast mm | 3350 | |||||||
| Aisle width for pallet 1000*1200 | Ast mm | 3050 | |||||||
| Performance | Turning radius | Wa mm | 1675 | ||||||
| Travel speed (full / empty load) | km/h | 6/6.2 | |||||||
| Lifting speed (full / empty load) | m/s | 105/150 | |||||||
| Lowering speed (full / empty load) | m/s | 220/105 | |||||||
| Max. gradeability (fully / empty load) | % | 5/8 | |||||||
| Brake type | Electromagnetic brake | ||||||||
| Motor | Driving motor power | kw | AC 1.5 | ||||||
| Lifting motor power | kw | 3 | |||||||
| Battery | V/Ah | 24/240 | |||||||
| Other | Weight of battery | kg | 200 | ||||||
| Control model | Field effect tube control | ||||||||
| Noise | dB(A) | <70 | |||||||
| Schedule | |||||||||
| a | Overall height | h1 mm | 2130 | 2330 | 1780 | 2030 | 2280 | 2430 | 2530 |
| b | Free lifting height | h2 mm | 1600 | 1800 | 90 | 90 | 90 | 90 | 90 |
| c | Lifting height | h3 mm | 1600 | 1800 | 2500 | 3000 | 3500 | 3800 | 4000 |
| d | Max. height | h4 mm | 2030 | 2230 | 3000 | 3500 | 4000 | 4300 | 4500 |
