CDD-D
欧能
steels
Suitable for factory workshop, square lobby airport, park and other high-altitude work needs of customers.
1.5-2.0T
PU
7
orange+black
500mm
Standing and driving style
Electric Pallet Stacker
AC Motor
Electric
1.6-4.0m
completely new
1 year or 1000 hours
provided
Surface painting
Support
CDD-D
ONEN
Italian brand
CE/RoHS/SGS
1.5/2.0T
| CDD-FS Electric Double Pallet Handling Stacker Technical Parameter | ||||||
| Feature | 1 | Model | CDD-D | |||
| 2 | Power type | Electric | ||||
| 3 | Steering type | Electric Steering | ||||
| 4 | Operating type | Stand-on | ||||
| 5 | Load capacity | Q | kg | 1500 | 2000 | |
| 6 | Load center distance | C | mm | 500 | ||
| 7 | Load distance, center of bearing axle to fork | X | mm | 400 | ||
| 8 | Wheel base | Y | mm | 1375 | ||
| Weight | 1 | Service weight with battery | kg | 1200 | 1250 | |
| Wheel | 1 | Wheel type | PU | |||
| 2 | Driving wheel size | mm | Φ230×75 | |||
| 3 | Balance wheel size | mm | Φ125×60 | |||
| 4 | Bearing wheel size | mm | Φ80×70 | |||
| 5 | Wheel quantity (Driving wheel/Balance wheel/Bearing wheel | 1/2/4 | ||||
| 6 | Track width (Balance wheel) | mm | 700 | |||
| 7 | Track width (Bearing wheel) | mm | 350/450 | |||
| Size | 1 | Mast lowered height | h1 | mm | 2200 | |
| 2 | Free lifting height | h2 | mm | 200 | ||
| 3 | Max. lifting height | h3 | mm | 3000 | ||
| 4 | Extended mast height | h4 | mm | 3660 | ||
| 5 | Overall size (Length×Width) | L1xb1 | mm | 2075x850 | 2115x850 | |
| 6 | Fork clearance from the ground | h5 | mm | 90 | ||
| 7 | Length to face of fork | L2 | mm | 927 | ||
| 8 | Fork size | s/e/l | mm | 230/60/1150 | ||
| 9 | Fork outer width | b3 | mm | 580/680 | ||
| 10 | Min. ground clearance | m | mm | 30 | ||
| 11 | Aisle width | Ast | mm | 2335 | ||
| Pallet 1000x1200（1000沿货叉边） | ||||||
| 13 | Turning radius | Wa | mm | 1940 | 1970 | |
| Performance | 1 | Driving speed (laden/ unladed) | km/h | 5/5.5 | ||
| 2 | Lifting speed (laden/ unladed) | m/s | 95/165 | 70/120 | ||
| 3 | Lowering speed (laden/ unladed) | m/s | 110/100 | 80/65 | ||
| 4 | Gradeability (Laden/Unladen) | % | 5/8 | |||
| 5 | Brake type | Electromagnetic brake | ||||
| Electrical Configuration | 1 | Driving motor | kw | 1.5（AC） | ||
| 2 | Lifting motor | kw | 2.5 | |||
| Battery | 1 | Voltage/Capacity of lead-acid battery | V/Ah | 24/210 or 24/240 | ||
| 2 | Lead-acid battery charger | V/A | 24/30 | |||
| 3 | Voltage/Capacity of lithium battery (Optional) | V/Ah | 24/150 or 24/200 | |||
| 4 | Lithium battery charger | V/A | 24/50 or 24/100 | |||
| Other | 1 | Sound level at driver's ear | dB(A) | <70 | ||
| Mast Table | |||
| Lift height | Mast lowered height | Free lift | Extended mast height |
| h3（mm） | h1（mm） | h2（mm） | h4（mm） |
| 1600 | 2230 | 1600 | 2230 |
| 2000 | 1735 | 200 | 2660 |
| 2500 | 1985 | 200 | 3160 |
| 3000 | 2200 | 200 | 3660 |
| 3300 | 2385 | 200 | 4060 |
| 3500 | 2450 | 200 | 4160 |
| 4000 | 2700 | 200 | 4410 |
Q1. Are you a factory or trading company?
A: We are a professional manufacturer of warehouse material handling equipment for more than 30 years, our factory Guangdong Onen New-resource Equipments Co., Ltd. Locates in Taishan City of Guangdong province.
Q2. Can I buy samples?
A: Sure, please feel free to contact with us for samples.
Q3. What is your lead time?
A: It depends on the order quantity and the season you place order. Usually we can ship within 7-15 days for small quantity, and about 30 days for large quality.
Q4. What is your payment term?
A: T/T, Western Union, MoneyGram, Paypal, L/C. Payment term is negotiable.
Q5. What is the shipping method?
A: Goods can be shipped by sea, by air, by railway, or by express. Please confirm with us before place order.
Q6: How do you make our business long-term and good relationship?
A: We keep good quality and competitive price to ensure our customers' benefit, Furthermore, we respect every customer as our friend and we sincerely do business with them, no matter where they are.
