Electric pallet trucks are available in many models. Some offer a range of performance features such as ramp lifts and traction aids. They also offer a number of options for customization. These include the ability to use a control drawbar.
Powered pallet trucks can be used for both indoor and outdoor use. Some models are available with 24V technology while others are available with lithium battery technology. Lithium battery technology is becoming more and more popular as it offers extreme flexibility and offers a long service life.
A few features of powered pallet trucks include the ability to level on inclines up to 15%. They also offer traction aids and on board chargers. They can also be recharged in a few minutes during breaks.
| CBD STAND-ON ELECTRIC PALLET TRUCKS (CASTING FORK) | |||||
| Feature | 1 | Model | CBD | ||
| 2 | Configuration No. | 50-F | |||
| 3 | Drive | electric | |||
| 4 | Steering mode | electronic steering | |||
| 5 | Type of operation | stand on | |||
| 6 | Load capacity | Q | kg | 5000 | |
| 7 | Load center | C | mm | 600 | |
| 8 | Load distance | X | mm | 970 | |
| 9 | Wheel base | Y | mm | 1595 | |
| Weight | 1 | Service weight with battery | kg | 750 | |
| Wheels | 1 | Wheels type | PU/iron wheel | ||
| 2 | Driving wheel size | mm | Φ230×75 | ||
| 3 | Balance wheel size | mm | Φ125×60 | ||
| 4 | Bearing wheel size | mm | Φ80×70 | ||
| 5 | Wheel quantity(front /rear)(x=Driving wheel) | 1x-4/2 | |||
| 6 | Track width,front | mm | 400/520 | ||
| 7 | Track width,rear | mm | 700 | ||
| Dimension | 1 | Overall size | L1×B×h1 | mm | 2040×850×1435 |
| 2 | Lift | h2 | mm | 200 | |
| 3 | Lowered fork height | h3 | mm | 85 | |
| 4 | Overall height(Max/min) | h6 | mm | 1435/985 | |
| 5 | Length to face of forks | L2 | mm | 890 | |
| 6 | Fork size | s/e/l | mm | 160/55/1150 | |
| 7 | Overall fork width | b1 | mm | 560/680 | |
| 8 | Min.ground clearance | m2 | mm | 30 | |
| 9 | Min.Aisle width for pallets 1000×1200 | Ast | mm | 2332 | |
| 10 | Turning radius | Wa | mm | 1890 | |
| Performance | 1 | Travel speed(laden/unladen) | km/h | 5.5/10 | |
| 2 | Lift speed(laden/unladen) | mm/s | 40/50 | ||
| 3 | Lowering speed(laden/unladen) | mm/s | 50/20 | ||
| 4 | Gradeability(laden/unladen) | % | 8/20 | ||
| 5 | Brake | electromagnetic | |||
| Electrical configuration | 1 | Drive motor | kw | AC 2.2 | |
| 2 | Lift motor | kw | 2.5 | ||
| 3 | Battery voltage/capacity | V/Ah | 24/240 | ||
| 4 | Battery weight | kg | 200 | ||
| Other Details | 1 | Type of drive control | AC | ||
| 2 | Sound leave at driver's ear to EN 12053 | dB(A) | <70 | ||
| CBD STAND-ON ELECTRIC PALLET TRUCKS TECHNICAL PARAMETERS | |||||||
| Feature | 1 | Model | CBD | ||||
| 2 | Configuration No. | 20-F | 25-F | 30-F | |||
| 3 | Drive | electric | |||||
| 4 | Steering mode | electronic steering | |||||
| 5 | Type of operation | stand on | |||||
| 6 | Load capacity | Q | kg | 2000/2500/3000 | |||
| 7 | Load center | C | mm | 600 | |||
| 8 | Load distance | X | mm | 970 | |||
| 9 | Wheel base | Y | mm | 1400 | |||
| Weight | 1 | Service weight with battery | kg | 600/650 | |||
| Wheels | 1 | Wheels type | PU | ||||
| 2 | Driving wheel size | mm | Φ230×75 | ||||
| 3 | Balance wheel size | mm | Φ125×50 | ||||
| 4 | Bearing wheel size | mm | Φ80×70 | ||||
| 5 | Wheel quantity(front /rear)(x=Driving wheel) | 1x-4/2 | |||||
| 6 | Track width,front | mm | 400/520 | ||||
| 7 | Track width,rear | mm | 515 | ||||
| Dimension | 1 | Overall size | L1×B×h1 | mm | 1850×725×1435 | ||
| 2 | Lift | h2 | mm | 200 | |||
| 3 | Lowered fork height | h3 | mm | 85 | |||
| 4 | Overall height(Max/min) | h6 | mm | 1435/985 | |||
| 5 | Length to face of forks | L2 | mm | 700 | |||
| 6 | Fork size | s/e/l | mm | 160/55/1150 | |||
| 7 | Overall fork width | b1 | mm | 560/680 | |||
| 8 | Min.ground clearance | m2 | mm | 30 | |||
| 9 | Min.Aisle width for pallets 1000×1200 | Ast | mm | 2132 | |||
| 10 | Turning radius | Wa | mm | 1695 | |||
| Performance | 1 | Travel speed(laden/unladen) | km/h | 5.2/6 | |||
| 2 | Lift speed(laden/unladen) | mm/s | 40/50 | ||||
| 3 | Lowering speed(laden/unladen) | mm/s | 50/40 | ||||
| 4 | Gradeability(laden/unladen) | % | 8/15 | ||||
| 5 | Brake | electromagnetic | |||||
| Electrical configuration | 1 | Drive motor | kw | AC 1.5 | |||
| 2 | Lift motor | kw | 1.2 | ||||
| 3 | Battery voltage | V | 24 | ||||
| 4 | Battery capacity | Ah | 150/210 | ||||
| 5 | Battery weight | kg | 145/185 | ||||
| Other Details | 1 | Type of drive control | AC | ||||
| 2 | Sound leave at driver's ear to EN 12053 | dB(A) | <70<> | ||||
