ONEN CPCD High Performance Four Wheels Counterbalance Diesel Forklift Truck

      The motor power system and the power transmission system adopt the domesticadvanced shock absorption technology to reduce the vibration from the powersystem and make the operator feel more comfortable.The configuration of highdefinition liquid crystal display device makes it convenient for the operator tounderstand the working state, expand the visual area, so that the operator to viewthe instrument more convenient and fast.
      ·Wide field of view door frame allows operators to obtain a larger field of view space.not only improve the work     efficiency, but also enhance the safety.
      ·Adjustable safety seat, make the operator feel more comfortable.
      ·Ultra-low non-slip pedal Specially set non-slip pedal.
Availability:
  • CPCD

  • 欧能

  • steels

  • drive

  • 3.0/3.5T

  • 4

  • Solid core tires

  • orange+black

  • 500mm

  • Adjustable seat type

  • Heavy Forklift

  • Diesel Engine

  • Diesel

  • 3.0-5.0m

  • completely new

  • 1 year or 2000 hours

  • provided

  • Surface painting

  • support

  • CPCD

  • ONEN

  • Italian brand

  • CE/RoHS/SGS

  • 3.0-3.5T

Made in China Factory Price Heavy Duty 2 Tons 3 Tons 5 Tons Four Wheels Counterbalance Internal Combustion Gas/ LPG/ Diesel Forklift with Double/ Triple Mast


Product Description

Forkliftdiesel forklift for saleMade in China Factory Price Heavy Duty 2 Tons 3 Tons 5 Tons Four Wheels Counterbalance Internal Combustion Gas/ LPG/ Diesel Forklift with Double/ Triple Mast

Technical Parameter
Model: CPCD2030 CPCD2530 CPCD3030 CPCD3530
Power Type: Diesel Diesel Diesel Diesel
Rated Load: 2000 kg 2500 kg 3000 kg 3500 kg
Load Center Distance: 500 mm 500 mm 500 mm 500 mm
Maximum Lifting Height: 3000 mm 3000 mm 3000 mm 3000 mm
Mast Tilt Angle (Front/ Rear): 6°/12° 6°/12° 6°/12° 6°/12°
Fork Size: L1070*W122*T40 mm L1070*W122*T40 mm L1070*W125*T45 mm L1070*W125*T45 mm
Fork Distance (max./ mim.): 1100 mm / 250 mm 1100 mm / 250 mm 1100 mm / 250 mm 1100 mm / 250 mm
Overall Length:
(without / with fork)
2570/3654 mm 2570/3654 mm 2750 mm / 3870 mm 2890 mm / 3980 mm
Overall Width: 1160 mm 1160 mm 1230 mm 1230 mm
Overhead Guard Height: 2130 mm 2130 mm 2140 mm 2140 mm
Turning Radius: 2340 mm 2340 mm 2470 mm 2640 mm
Min. Intersecting Aisle: 2400 mm 2400 mm 2120 mm 2700 mm
Max. Gradeablility: 20% 20% 20% 20%
Tire QTY. (x= driving tire, F/R): 2x/2 2x/2 2x/2 2x/2
Tire Type: Pnuematic Tire Pnuematic Tire Pnuematic Tire Pnuematic Tire
Transmission: Manual Transmission Manual Transmission Manual Transmission Manual Transmission
Engine: Chinese XinChai C490 Chinese XinChai C490 Chinese XinChai C490 Chinese XinChai C490
Self Weight: 3480 kg 3480 kg 4280 kg 4500 kg


diesel forklifts5 ton forklift

About Us

warehouse forklift for saleforklifts

Work Shop


diesel forklift manufacturers

Cooperation Brand


diesel forklifts

Packing And Logistic


diesel forklift for sale

Why Choose ONEN


Q1. Are you a factory or trading company?
A: We are a professional manufacturer of warehouse material handling equipment for more than 20 years, our factory Guangdong Onen New-resource Equipments Co., Ltd. Locates in Taishan City of Guangdong province.

Q2. Can I buy samples?
A: Sure, please feel free to contact with us for samples.

Q3. What is your lead time?
A: It depends on the order quantity and the season you place order. Usually we can ship within 7-15 days for small quantity, and about 30 days for large quality.

Q4. What is your payment term?
A: T/T, Western Union, MoneyGram, Paypal, L/C. Payment term is negotiable.

Q5. What is the shipping method?
A: Goods can be shipped by sea, by air, by railway, or by express. Please confirm with us before place order.

Q6: How do you make our business long-term and good relationship?
A: We keep good quality and competitive price to ensure our customers' benefit, Furthermore, we respect every customer as our friend and we sincerely do business with them, no matter where they are.
