CPC/CPCD-3030 Diesel Forklift

Load Capacity: 3000kg
lift height: 3000mm
engine model: Xinchai / Quanchai / YANMAR / KUBOTA
Availability:
  • CPC/CPCD-3030

  • ONEN

  • Counterbalanced Diesel Forklift

  • Diesel

  • 3.0T

  • Seated

  • 500mm

  • Pneumatic Tire / Solid Core Tire

  • 3m

  • 1070mm

  • 2240mm

  • 60L

  • Xinchai / Quanchai / YANMAR / KUBOTA

  • Single Sided Tray, Double Sided Tray

  • 12V/80Ah

  • support

  • Warranty for one year or 1000 hours

  • CE/RoHS/SGS


图片-1

CPC/CPCD-3030 diesel forklift is widely used in heavy-duty and outdoor work environments. Its counterbalanced design and robust diesel power make it particularly suitable for scenarios such as ports and docks, factory floors, construction sites, and logistics parks.




361

CPC/CPCD-3030 can effectively handle sloping roads, adverse weather conditions, and long-duration continuous operations. It excels in high-intensity and low-frequency tasks such as handling steel, stone, heavy pallets, and container loading and unloading, offering significant advantages of strong power, good trafficability, and long endurance.


1 Model
CPC3030/CPCD3030
2 Powertype
diesel
3 Operation type
seated
4 Load capacity kg 3000
5 Load centre distance mm 500
6 Wheels type
Solid tires/Pneumatic tires(Optional)
7 Tire specification(Front/Rear)
28x9-15/6.50-10
8 Fork length mm 1070
9 Width overall forks (Adjustable) mm 1100/250
10 Overall Length (Without fork) mm 2690
11 Overall Width mm 1210
12 Lift height mm 3000
13 Extended mast height mm 3560
14 Mast lowered height mm 2100
15 Free height mm 165
16 Tilt of mast carriage (Forward/Backward) α/β 6°/12°
17 Turning radius mm 2240
18 Travelspeed (Laden/Unladen) km/h 18/20
19 Lift speed (Laden/Unladen) mm/s 485/505
20 Lowering speed (Laden/Unladen) mm/s <600
21 Gradeability (Unladen) % 20
22 Service brake
Power brake (Pedal)
23 Parking brake
Mechanical (Manual)
24 Fuel capacity L 60
25 Engine model
Xinchal/Quanchai/YANMAR/KUBOTA
26 Battery (Voltage/Capacity) V/Ah 12/80
