ONEN 2.0T Electric Stand-on Pallet Stacker (Economic Model) CDD-B

Model: CDD-B
Rated Load: 2,000 kg
Max. Lift Height:1.6-4.5m

Product Overview

What if one compact machine could pick, transport, lift and stack — replacing both a pallet truck and a sit-down forklift in your daily operation? The ONEN CDD-B 2.0-ton stand-on stacker is that machine. Purpose-built for distribution centers, factory floors, supermarket backrooms, railway stations and port sheds, it executes four composite operations in a single work cycle: order picking, horizontal transport, loading and unloading, and finished-goods stacking.

With a rated capacity of 2,000 kg at a 500 mm load center and a mast range spanning 1.6 m to 4.5 m, the CDD-B adapts to everything from ground-level shuttle runs to high-bay racking. The folding stand-on platform lets operators ride between zones on long hauls, then step off and work on foot for millimeter-accurate fork positioning — a flexibility walk-behind stackers simply can't match.

Beneath the covers, a 24 V / 80 Ah lead-acid battery paired with a 24 V / 10 A charger delivers up to 5 km/h unladen travel and smooth 120–160 mm/s lifting, while electromagnetic plus reverse braking brings the truck to a confident, wear-free stop every time. Every unit rolls off the line at Guangdong ONEN New-resource Equipments Co., Ltd. — a manufacturer with three decades of material-handling expertise.

5 Core Advantages

1. Five-Point Chassis with Automatic Turn Slow-Down

The frame distributes load across five strategically placed support points, keeping the center of gravity low and balanced — with or without a 2-ton pallet aboard. An intelligent auto-deceleration function engages the moment the steering wheel is turned, suppressing lateral sway even with forks raised. Narrow-aisle stacking feels planted, predictable and safe.

2. Zero-Brush AC Vertical Drive Motor

The vertical drive motor layout puts every service point within easy reach — no gearbox, no complexity. As a true AC brushless system, there are no carbon brushes to inspect or replace, cutting scheduled maintenance to an absolute minimum and keeping fleets on the floor longer.

3. High-Power Hydraulic Pump Station for Butter-Smooth Lifting

A dedicated hydraulic power unit delivers strong, consistent pressure, so a fully loaded carriage rises and lowers in one fluid motion. No jerking at the start, no drift at height — fragile goods arrive at the top shelf exactly as they left the ground.

4. Low-Noise, Low-Vibration Multi-Function Handle

Every drive and lift function falls naturally under the operator's thumbs. The tiller head integrates reverse-gear braking for instant stopping when the operator steps back, plus a turtle/rabbit dual-speed mode that toggles between creep-speed precision and full transit pace at the press of a button. Operator-ear noise stays below 70 dB(A) — quiet enough for retail backrooms.

5. Core Components from Top-Tier Global Brands

Contactors, controllers, hydraulic seals and bearings are sourced from premium international component partners, ensuring interchangeability, extended service life and a dependable worldwide spare-parts supply chain.

Where This 2.0-Ton Stacker Earns Its Keep

High-Density Warehousing & Distribution With lift options reaching 4.5 m, the CDD-B services tall racking and mezzanine levels that walkie stackers can't touch — yet its 1,300 mm turning radius and 2,200 mm working aisle (platform folded) keep storage density high and aisle space minimal.

Heavy-Duty Factory Workshops At 2,000 kg capacity, it feeds raw materials to assembly stations and clears finished-goods pallets in one trip. Operators ride the folding platform between production zones, then dismount for precise placement at the rack face.

Retail & Supermarket Backrooms Sub-70 dB(A) noise and zero exhaust make it safe beside customer areas, while the 85 mm lowered fork height slides under standard single-layer pallets for fast, quiet restocking.

Logistics Terminals, Stations & Ports Sealed electrics and a robust welded chassis shrug off the dust, humidity and non-stop cycles of cross-dock terminals and port sheds — keeping trailers and containers turning on schedule.

Factory Profile & Certifications

Guangdong ONEN New-resource Equipments Co., Ltd. brings 30 years of material-handling manufacturing experience to every unit, running the full production chain in-house — steel cutting, robotic welding, painting, assembly and 100% load testing. Each CDD-B ships export-ready with:

• ISO 9001 Quality Management

• ISO 14001 Environmental Management

• ISO 45001 Occupational Health & Safety

• CE Attestation of Compliance

• RoHS Environmental Compliance

• SGS Supplier Audit

• Special Equipment Production License

• Canton Fair Design Award Recognition

We welcome on-site factory inspections, live video audits and third-party pre-shipment testing for volume partners.

Frequently Asked Questions

Q: What capacity and lift heights does this model cover? A: This CDD-B configuration is rated at 2.0 tons with lift heights from 1.6 m up to 4.5 m. Multiple mast options let you match the truck to your rack heights and ceiling clearance — you never pay for lift you don't use.

Q: Is the battery included? Can I upgrade to lithium later? A: Every unit ships with a sealed 24 V / 80 Ah lead-acid battery and matched 24 V / 10 A charger. The battery compartment is designed to accept lithium packs, so retrofitting is straightforward whenever you're ready.

Q: What aisle width do I need? A: For standard 1,000 × 1,200 mm pallets, the right-angle stacking aisle is approximately 2,200 mm with the platform folded. Send us your pallet and rack layout and we'll confirm the exact figure.

Q: Which pallets can it handle? A: The 560/680 mm adjustable fork spread and 1,150 mm fork length suit common single-layer pallets; custom fork dimensions and attachments are available for special loads.

Q: Do you support OEM / private-label orders? A: Yes — custom colors, branding decals, fork dimensions, battery options and regional voltage standards are all available for OEM/ODM partners.

Q: How demanding is daily maintenance? A: Minimal: a visual inspection, keeping PU wheels clear of debris, and routine battery care. Electromagnetic braking is wear-free, and the AC motor needs no brush replacement — so service intervals are long and running costs stay low.

Get Your Factory-Direct Quote Today

Ready to stack higher, move faster and spend less per pallet?

• Competitive EXW / FOB / CIF pricing on the CDD-B series

• Volume fleet discounts and mixed-model container loading

• Custom mast heights up to 4.5 m, lithium upgrades, OEM/ODM livery

• On-site inspection and live video audit scheduling
