CQD-B-2045-Q Electric Reach Truck

Name: CQD-B-2045-Q Electric Reach Truck
Brand: ONEN
Rating: 5.0 (57 reviews)

ONEN CQD-B stacking vehicle supports a rated load of 2 tons and has a maximum lifting height of up to 4.5 meters (optional). The vehicle adopts a sit-down design with electronic steering, providing comfortable and flexible operation. Its compact body is suitable for narrow storage aisles. Equipped with a multi-valve hydraulic system and a high-strength chassis, it ensures stability and safety during stacking operations, making it an efficient solution for heavy-duty stacking.

Availability:



Inquire Add to Basket

Model:
CQD-B-2045-Q
Brand:
ONEN
Name:
Electric Reach Truck
Power form:
Electric
Load Capacity:
2000kg
Driving Style:
Seated
lift height:
4500mm
Battery:
Lead-acid / Lithium
Use Tray Type:
Single Sided Tray, Double Sided Tray
Certification:
CE/RoHS/SGS

ONEN CQD-B stacking truck (with a load capacity of 2 tons and a lifting height of 4.5 meters) is particularly suitable for high-level automated warehouses and narrow aisle operations. Its forward-moving design allows for flexible maneuvering in confined spaces, efficiently completing the high-level stacking and picking of heavy palletized goods.

The sit-down operation reduces driver fatigue during high-frequency, high-altitude operations, making it an ideal choice for improving warehouse space utilization and logistics transfer efficiency.

ONEN CQD-B forklift sit-down reach truck 2-ton storage forklift 4.5-meter shelf forklift warehouse high-level stacking vehicle quality-assured lithium battery electric reach truck reach truck Manufacturer China reach truck Reach Truck Forklift

1	Model		CQD-B
2	Configuration No.		2045-Q
3	Power type		Electric
4	Steering type		Electric steering
5	Operation type		Seated
6	Load capacity	kg	2000
7	Load center distance	mm	500
8	Reach Distance	mm	505
9	Wheels type		PU
10	Driving wheel size	mm	Ф382×142
11	Bearing wheel size	mm	Ф267×114
12	Overall Length (With Fork)	mm	2477
13	Overall Width	mm	1270
14	Mast lowered height	mm	2100
15	Lift height	mm	4500
16	Extended mast height	mm	5465
17	Fork dimensions	mm	35/100/1070
18	Turning radius	mm	1800
19	Travel speed (Laden/Unladen)	km/h	6.8/7.8
20	Lift speed (Laden/Unladen)	mm/s	120/240
21	Lowering speed (Laden/Unladen)	mm/s	315/260
22	Gradeability (Laden/Unladen)	%	≤10
23	Driving motor	kw	6.5
24	Lifting motor	kw	4.5
25	Voltage/Capacity of lead-acid battery	V/Ah	48/300
26	Lead-acid battery charger	V/A	24/40
27	Voltage/Capacity of lithium battery (Optional)	V/Ah	48/280
28	Lithium battery charger	V/A	24/50
29	Sound level at driver's ear	dB(A)	<70

Mast Table
Lift height	Mast lowered height	Free lift	Extended mast height
h3（mm）	h1（mm）	h2（mm）	h4（mm）
3000	2100	‐	3577.5
3500	2350	‐	4077.5
4000	2600	‐	4577.5
4500	2100	1500	5465
5000	2280	1660	5965
5500	2450	1820	6465
6000	2620	1980	6965
6500	2790	2140	7465
7000	3210	2320	7965
